Products  -   SS  series   Class S Stainless Steel Precision Shafts

SS series Class S Precision Linear Shaft
Part Number
Dimensions and Specs
Machining Options
Product  Overview
Model Number: SS  series
Shaft Tolerance: Class S
Key Feature: Cut to Length Linear Shafts
Material: 1060 Steel or
440C Stainless Steel Shafting
Shaft Diameters: 0.250 to 2.000 inches
Maximum Lengths: 184 inches
Matching Bearings: LBCA  and  LBOA
Delivery: Stock
Get a Price            Get a CAD File
SS series Precision Linear Shafts
SS series Precision Linear Shafting
LinTech offers "Cut to length" Class S steel and stainless steel precision linear shafting. 1060 Carbon steel shafting is available from 0.250 to 2.000 inch diameters. 440C stainless steel precision linear shafting is available from 0.250 to 2.000 inch diameters also. Any length is available within .001 inch increments, up to the standard maximum stocked lengths. Any precision linear shaft can also be machined per drawings which are supplied by the customer (i.e. radial and coaxial holes, dowel joints, butt joints, reduced diameters, threaded ends, machined mounting holes, keyways, special chamfers, etc.).
PDF  File  Down  Loads
                   SS  Technical Information            Design Section Components
                   Entire Components Catalog            Components Service Manual
Product  Resources
Get a Price Get a CAD File
